PT Eleven Nesting Dinghy Nesting Dinghy Base Kit

The PT 11 Nesting Dinghy Base Kit includes:

• Machined Joubert Okoume plywood parts in 6mm, 12mm, 15mm, 18mm, 25mm
• High grade Sitka spruce lumber kit for glue cleats & mahogany back seat cleats
• WEST System 105/207 epoxy kit with metering pumps and 404, 406, 407, and 410 fillers
• Molded and predrilled carbon fiber alignment clips + fasteners
• Machined 316 SS connective hardware (4/boat)
• Machined G-10 star knobs
• 2 1/8” ID molded fiberglass mast step socket tube & machined plywood mast step partners
• Daggerboard trunk kit; includes plywood walls + pre-fiberglassed trunk logs + 1/32” -  G-10 strip for trunk edges
• Fiberglass tube for towing eye
• Fiberglass: 10 yds x 50” 4oz cloth, 8 yds x 50” 6oz cloth for chine taping and hull bottom and local reinforcements, 2 1/4 yds x 60” peel ply for chine taping
  54” long fiberglass sail batten for skeg chafe cap
• 1/16” spacer stock w/ double sided tape attached for separating connective bulkheads
• 1/2” alignment dowels for aligning connective bulkheads
• Plywood material for nail & screw pads
• Hull gasket material
• Machined fillet stick set
• Spiral-bound assembly manual
• Wire
• USCG capacity sticker
• Paper template for locating foot braces
• Water-tight Hatch kit for the foredeck
• Low profile G10 water tight daggerboard trunk cap kit
• Laser cut leather chafe pads
• Sapele marine plywood back seat

Kit Pickup Note- The PT11 & Spear epoxy kits are drop shipped from West System directly to the customer. An epoxy shipping fee will still apply for all kits that are picked up at the CLC facility or event. Call for more details.
